ISUZU 6 Ton Dump Truck

ISUZU 6 Ton Dump Truck

A. Platform & Configuration
Built on the proven ISUZU 700P QL1100A8HAY 4×2 LHD chassis, this dump truck combines agile maneuverability with heavy-duty performance. It features a 3,360mm wheelbase optimized for tight urban worksites and rural access roads.

B. Powertrain & Emissions

• Engine: ISUZU 4HK1-TC51 turbocharged diesel (5.193L displacement) delivering 190 horsepower with Euro 5 compliance, ensuring high torque output and minimal environmental impact.
• Transmission: ISUZU MLD-6Q manual gearbox (6 forward + 1 reverse gears) for precise load management and reliability under continuous operation.

C. Axles, Tires & Cab

• Axle Capacity: 4,000kg front axle and 6,000kg rear axle for balanced load distribution.
• Tire System: 235/75R17.5 16PR tires (6 wheels + 1 spare) for durability on mixed terrain.
• Operator Environment: Single-row cab (white finish) with seating for 2 persons, equipped with air conditioning, power-assisted steering, and an MP3-compatible audio system to enhance driver comfort during extended shifts.

Features: Optimized Dump Body & Hydraulic System

A. Dump Body Design & Construction

• Dimensions & Capacity: A 3,800 × 2,105 × 600mm (L×W×H) steel body engineered for a 6-ton payload, utilizing Q235 high-tensile steel (equivalent to IS-2062 Gr.A / ASTM A36) for exceptional structural resilience.
• Reinforcement: Vertical “H”-type steel profiles integrated into the body and tailgate to resist deformation under heavy or abrasive loads.
• Tailgate Flexibility: Hinged top-mount design with optional automatic locking or hydraulic operation for adaptable unloading scenarios.

B. Hydraulic Performance & Control

• Lifting Mechanism: Middle-lifting hydraulic system with a Chinese renowned-brand cylinder ensuring smooth, reliable hoisting cycles.
• Discharging Efficiency: 45° dumping angle for rapid material ejection without residue buildup.
• Operational Versatility: Hydraulic controls enable both tilt-based self-unloading and horizontal push-unloading, allowing operators to adapt to site-specific constraints like overhead obstacles or confined spaces.

C. Durability Enhancements

• Steel Thickness: 3mm side walls and 4mm floor plating resist impact and abrasion from aggregates or demolition debris.
• Corrosion Resistance: Advanced paint treatments and material specifications extend service life in humid or chemically aggressive environments.
