ISUZU 11 CBM Vacuum Tank Truck

ISUZU 11 CBM Vacuum Tank Truck

The ISUZU 11 CBM Vacuum Tank Truck is a professional sanitation vehicle designed for efficient collection, transportation, and discharge of sewage, sludge, wastewater, and other liquid waste materials. Built for municipal cleaning, industrial waste handling, septic tank maintenance, and drainage system services, this vacuum tanker combines a durable tank structure with a powerful vacuum suction system to deliver reliable performance in demanding working environments.

Equipped with an 11 cubic meter sewage tank, the truck provides a practical balance between carrying capacity and operational flexibility, allowing operators to complete more cleaning tasks while reducing the frequency of unloading. The tank is manufactured from high-quality Q235 carbon steel with a 6mm thickness, providing strong structural strength and excellent durability for long-term operation under vacuum pressure and heavy-duty working conditions.

The vehicle adopts a high-performance Veyron 68/7000 vacuum pump, which generates a maximum vacuum pressure of -0.093 MPa and delivers strong suction capability for removing sewage, sludge, and liquid waste from septic systems, drainage pipelines, and underground chambers. With a maximum suction lift of approximately 9 meters, the truck can handle various cleaning applications even in locations with difficult access.

Designed with a hydraulic self-unloading system, the ISUZU Vacuum Tank Truck can discharge collected materials efficiently without requiring additional equipment. The hydraulic lifting mechanism allows the sewage tank to tilt up to 23°, helping operators complete unloading operations faster while improving overall working efficiency.

Features

Powerful Vacuum Suction System

The most important feature of this truck is its reliable vacuum loading system, which is designed to provide continuous and stable suction performance during sanitation operations. The installed Veyron vacuum pump 68/7000 delivers strong airflow and vacuum generation capability, making it suitable for collecting sewage, sludge, industrial wastewater, and other liquid waste materials.

With a vacuum degree reaching -0.093 MPa, the system provides sufficient suction force for deep cleaning applications, while the maximum suction height of 9 meters allows operators to work efficiently on different types of sewer and drainage systems. The suction process is supported by a large-diameter suction pipe with a diameter of 100mm, ensuring smooth material flow and reducing the risk of blockage during operation.

The vacuum system is designed for professional cleaning work where reliability and speed are essential, making the truck suitable for municipal sanitation departments, environmental service companies, and industrial maintenance operations.

Durable 11 CBM Sewage Tank Structure

The tank body is manufactured using Q235 high-strength carbon steel, a commonly used material for heavy-duty special vehicles due to its excellent strength, toughness, and resistance to deformation. With a material thickness of 6mm, the sewage tank is built to withstand repeated vacuum loading cycles and transportation conditions.

The 11 CBM tank capacity provides sufficient storage space for large-volume waste collection, allowing the vehicle to complete longer working routes with fewer unloading stops. The tank design focuses on both durability and practicality, ensuring reliable operation in urban sanitation projects, factory wastewater treatment, and septic cleaning services.

The internal structure is optimized for sewage transportation, while the strong tank body helps maintain safety and stability during vacuum operation and road transportation.

Efficient Hydraulic Self-Unloading System

The ISUZU truck is equipped with a hydraulic lifting discharge system that simplifies the unloading process after waste collection. Instead of requiring manual handling or additional machinery, the tank can be raised hydraulically to release collected sewage and sludge efficiently.

The hydraulic system operates at a working pressure of 16 MPa, providing stable lifting performance and reliable operation. The rear unloading design with a maximum discharge angle of 23° helps improve waste flow during emptying, reducing remaining material inside the tank and improving cleaning efficiency.

The manual control system offers simple operation and allows drivers or operators to easily manage suction, lifting, and unloading functions during daily work.

Reliable Solution for Municipal and Industrial Cleaning

The ISUZU 11 CBM Vacuum Tank Truck is designed as a versatile sanitation vehicle that can handle a wide range of applications, including septic tank cleaning, sewer maintenance, industrial wastewater collection, and environmental protection projects. Its combination of a large-capacity tank, powerful vacuum pump, and hydraulic unloading structure makes it an efficient choice for professional cleaning operations.

Compared with standard waste transportation vehicles, this vacuum tanker provides specialized suction capability, allowing it to remove liquid waste directly from underground systems and confined areas. When combined with other municipal equipment such as a sewer truck, sweeper truck, and garbage truck, the ISUZU sanitation vehicle lineup can support comprehensive urban cleaning and environmental management tasks. Supported by the reliable engineering of ISUZU Vehicles, this vacuum tank truck delivers dependable performance for customers seeking long-lasting and efficient waste management solutions.

Specifications
