SPECIFICATIONS:
Attribute | Description |
---|---|
Chassis Brand | Qingling Isuzu KV600 |
Box Length | 5020mm |
Engine | Isuzu 131 horsepower engine 4KH1CN6HB |
Transmission | Isuzu 6-speed manual |
Wheelbase | 3815mm |
Tires | 7.50R16LT tires |
Emission Standard | EURO 2, EURO 3, EURO 4, EURO 5, EURO 6 |
Chassis Standard | KV600 wide cab, 131 horsepower National VI 4KH1CN6HB engine, Isuzu 6-speed manual transmission, equipped with air conditioning, power steering, central locking, power windows, multifunctional LCD dashboard, front axle 3.3 tons, rear axle 5.5 tons, ABS, 7.50R16LT tires, pneumatic brake |
Exterior Dimensions | 7025×2270×3300(mm) |
Box Dimensions | 5020×2100×2100(mm) |
Gross Vehicle Weight | 8280(Kg) |
Curb Weight | 4000(Kg) |
Allowed Load | 4085(Kg) |
Refrigeration Range | Minus 5 degrees to minus 18 degrees Celsius |
Refrigeration Unit | Cold King KV500 |
Optional Units | Jingda K, HanYa, Hansnow, Huatai, Songhan, Kaisnow, American Carrier, American Cold King, and others |
Box Configuration | Interior and exterior are made of the latest nano fiberglass material, 8cm thick insulation, rust-resistant WISCO high-quality light steel profiles for the inner frame, polyurethane foam insulation, aluminum alloy checkered plate or optional nano fiberglass for the bottom, galvanized stainless steel corners, thickened aluminum alloy edging, stainless steel rear door frame, thickened stainless steel rear door hinges and locks, LED interior lighting, and width indication lights inside the box |
Ventilation System | Optional T-shaped ventilation slots, bottom plate ventilation slots, ventilation partitions around the interior of the box |
Optional Configurations | Guide rails for meat hooks, T-shaped ventilation slots, right-side opening side door, real-time temperature and humidity monitoring with printing device. For seafood boxes, the interior must be made of stainless steel, optional external power supply (box refrigeration operates through an external power supply when the vehicle is stopped) |
