GENERAL | |
Make/Model | ISUZU / BT05QL130L5 |
Drive Type | 4×2 Left-Hand Drive |
Overall Dimension
(L x W x H) |
6,300×2,280×2,550 (mm) |
Gross Vehicle Weight | 7,970kg |
Curb Weight | 4,970kg |
Wheelbase | 4,360mm |
Chassis Designed | ISUZU 600P |
Cabin | Hydraulic power steering type.
1 driver+2 passengers |
Drive wheel(Tires ) | 4+2 and one spare (total 7 wheels) |
Tire Size | 7.00R16 |
ENGINE | |
Make / Model | ISUZU / 4KH1CN5HS |
Type | 4 cylinders in line, 4 strokes direct injection, water cooling, Intercooled Turbocharged |
Displacement | 2.999L |
Nominal Power | 130HP (96kW) @ 3,400rpm |
Peak Torque | 290N.m@1,500rpm |
Emission Standard | Euro 5 |
TRANSMISSION | |
Make / Model | ISUZU/MSB |
Type | Diesel |
Operation | Manual |
Number of Speeds | 5F+1R |
Upper Body | |
Capacity | 5m3 |
Bitumen Pump | QGB680 (high viscosity, made in China) |
Hydraulic Motor | 05-130-BD31 |
Hydraulic pump | CBQ550-L |
Spray Medium | Emulsified Asphalt, Hot Asphalt, Modified Asphalt |
Spray Amount | 0.25-2.5 Liters Per Square Meter |
Spray Wdth | 0~6m |
Burner | G10(Made in Italy) (200000 kcal/h) |
Heating-up Mode | Self-Heating by Thermal Oil |
Control System | Manual operation, Rear Control Panel |
Make/Model | ISUZU/ BT05QL130L5 |
GVW | 7,970kg, Medium Duty Vehicle |
Cab Truck | ISUZU 600P 4×2 Day Cab |
Engine | ISUZU/4KH1CN5HS/130hp/Euro 5 |
Transmission | ISUZU/MSB manual 5+1 Speed |
Tank Capacity | 5 Cubic Meters |
Spray Width | 6m |
Categories: ISUZU Construction Truck, ISUZU ELF Truck, ISUZU Trucks for Sale
Certification | CCC, ISO14001:2015, ISO45001∶2018, ISO9000, ISO9001:2015, RoHS |
---|---|
Color | Customized Color |
Condition | New |
Customized | Yes |
Delivery Time | 50 Days |
Drive Mode | 4×2 |
Emission Standard | Euro V |
Intercom | CFR, CIF, CIP, CPT, DAF, DAP, DAT, DDP, EXW, FCA, FOB |
Packaging Details | Waxed |
Power Type | Diesel |
Shipping Vessel | Bulk Shipment, Container Shipment, Flat Rack, FR Container Shipment, RORO Shipment |
Steering | LHD |
Terms of Payment | T/T |
Truck Class | Medium Duty |
Warranty Period | 12 Months |
