ISUZU EV100 1.5 Ton Van Box Truck

ISUZU EV100 1.5 Ton Van Box Truck

Engineered for precision urban delivery, the ISUZU EV100 1.5T Van Box Truck redefines sustainable logistics with its pure electric architecture and optimized payload efficiency. Manufactured in Chongqing, this 4X2 light-duty truck integrates a compact 5.995-meter footprint with a strategically balanced 3360mm wheelbase, enabling exceptional maneuverability in congested city streets and narrow industrial zones. Designed for maximum operational uptime, it delivers a 330km CLTC-certified range on a single charge while accommodating a robust 1.415-tonne payload within its reinforced van body—translating to fewer charging interruptions and higher daily delivery cycles. The vehicle’s 2.95-tonne curb weight (GVWR: 4.495 tonnes) leverages advanced lightweight materials to enhance energy efficiency without compromising structural integrity, while its 4.2-meter cargo box (internal: 4.25L×2.05W×2.1H) offers 18.3m³ volumetric capacity for palletized goods, e-commerce parcels, or temperature-sensitive freight. With a 100km/h top speed and compliance-ready emissions-free operation, this model stands as a future-proof investment for modern fleets navigating emission-restricted urban zones.

Technical Features

I. Electric Powertrain & Energy Management

• High-Torque Motor System: Rear-mounted Shanghai Electric Drive YTD060W23 permanent magnet synchronous motor generates 60kW continuous power and 110kW peak output, with a forceful 1000N·m torque enabling confident hill starts and loaded acceleration.
• Advanced Battery Technology: 96.77kWh lithium iron phosphate (LFP) battery from CATL (model L140T26) ensures thermal stability and longevity, supported by standard DC fast charging (20-80% in ≈50 mins) and optional AC slow charging for depot overnight replenishment.

II. Cargo Optimization & Structural Design

• Purpose-Built Van Truck Body: Seamlessly enclosed cargo box with 4.25-meter internal length accommodates Euro-pallet configurations, while corrosion-resistant composite walls ensure durability in high-frequency loading environments.
• Payload Intelligence: Strategic weight distribution leverages a 1,805kg front / 2,690kg rear axle load capacity, maximizing stability during cornering and uneven urban terrain.

III. Safety & Drivetrain Engineering

• Braking Integrity: Standard ABS paired with hydraulic drum brakes (front/rear) ensures controlled stops under full-load conditions.
• Terrain-Adaptive Tires: Six 7.00R16 8PR tires deliver puncture resistance and enhanced traction on wet roads, reducing downtime from blowouts.

IV. Operator-Centric Cabin

• Efficient Spatial Layout: Two-seat single-row cab prioritizes driver ergonomics with intuitive controls and panoramic visibility for urban navigation.
• Essential Comfort Features: Includes manual air conditioning and optimized noise insulation (<70 dB) for reduced fatigue during extended shifts.

ISUZU Vehicles Operational Advantages

• Cost Efficiency: 40% lower per-kilometer operating costs versus diesel equivalents, with exemption from congestion/emission fees in metropolitan zones.
• Sustainability Metrics: Zero tailpipe emissions and 98% recyclable battery components align with ESG targets for green logistics.
• Reliability Focus: IP67-rated battery enclosure and motor protection ensure consistent performance in extreme temperatures (-20°C to 50°C).
