ISUZU Flatbed Tow Truck with Crane
The ISUZU Flatbed Tow Truck with Crane is a versatile heavy-duty recovery vehicle designed to handle accident recovery, vehicle transportation, machinery relocation, and roadside rescue with outstanding efficiency. Built on the dependable ISUZU FVZ 6×4 chassis, this integrated recovery truck combines a high-capacity flatbed, hydraulic wheel lift, powerful winch, and XCMG knuckle boom crane into one professional solution for demanding towing operations.
Powered by a reliable 280 HP ISUZU 6HK1 diesel engine and equipped with a manual transmission, the truck delivers excellent driving performance while supporting lifting, towing, loading, and recovery tasks in construction sites, highways, logistics centers, and municipal rescue services. Its durable hydraulic system and reinforced structure ensure dependable operation under heavy workloads.
Features
Heavy-Duty ISUZU Recovery Chassis
The tow truck is built on an ISUZU FVZ 6×4 left-hand-drive chassis with a 5,700 + 1,300 mm wheelbase, steel leaf spring suspension, drum brakes, and durable 11.00R20 tires. The spacious day cab with air conditioning provides a comfortable working environment for long-distance recovery operations.
High-Capacity Flatbed and Wheel Lift
The reinforced 8,200 mm × 2,350 mm flatbed is designed to transport vehicles weighing 12 to 15 tons, while the hydraulic wheel-lift system offers an impressive 8,100 kg retracted lifting capacity and 4,000 kg extended lifting capacity, allowing operators to recover a wide range of passenger cars, buses, and commercial trucks safely and efficiently.
Powerful Winch and Knuckle Boom Crane
A 15,000 kg hydraulic worm-gear winch with a 45-meter steel cable provides reliable pulling power for difficult recovery situations. The integrated XCMG SQ2200B knuckle boom crane delivers up to 10,000 kg lifting capacity, a maximum outreach of 12.75 meters, 206 kN·m lifting moment, and 410° continuous rotation, making loading and lifting operations faster and more flexible.
Professional Hydraulic System and Accessories
The truck comes equipped with a complete hydraulic assembly, dual-side control stations, wire remote control, front-mounted light pylon, stainless steel door handles, and extended stabilizers for enhanced operational safety. A complete set of recovery accessories, including frame forks, fork adapters, ratchet straps, towing trolleys, and hook chains, enables the vehicle to perform a wide variety of professional towing and rescue tasks with maximum efficiency.
Specification
| Category & Item | Specification Description |
| 1. Basic Vehicle Information | |
| Vehicle Model | ISUZU FVZ Flatbed Tow Truck |
| Model Number | CSC5250FBOL |
| 2. Chassis Specifications | |
| Chassis Model | ISUZU FVZ 280 6×4 Left Hand Drive |
| Wheelbase | 5700 + 1300 mm |
| Cab Type | FVZ Day Cab with A/C |
| 3. Engine Specifications | |
| Engine Model | 6HK1-TCSG40 |
| Maximum Horsepower | 280 hp |
| 4. Transmission & Suspension | |
| Transmission | 9JS119TA, Manual |
| Suspension Type | Steel leaf spring suspension |
| 5. Brake & Tire Specifications | |
| Brake System | Drum Brake front and rear axle |
| Tire Specification | 11.00R20 with spare tire |
| 6. Flatbed Assembly | |
| Flatbed Dimensions (L×W) | 8200 × 2350 mm |
| Flatbed Load Capacity | 12,000 kg – 15,000 kg |
| Tilt Angle | 10° |
| 7. Winch Assembly | |
| Winch Type | Hydraulic winch, worm gear type |
| Winch Capacity | 15,000 kg |
| Cable Specification | 19 mm diameter, 45 m length |
| Installation Position | Front deck centre mounted |
| Quantity | 1 set |
| 8. Wheel Lift Assembly | |
| Boom Structure | Two boom weldment extend |
| Crossbar | Crossbar weldment |
| L Arm | Right & left L arm |
| Wheel Grid | Standard wheel grid |
| Lifting Rate (Retracted) | 8,100 kg |
| Lifting Rate (Extended) | 4,000 kg |
| 9. Crane Assembly | |
| Crane Model | XCMG Knuckleboom Crane SQ2200B |
| Lifting Capacity at 2.0m | 10,000 kg |
| Maximum Outreach | 12.75 m |
| Maximum Lifting Moment | 206 kNm |
| Hydraulic Oil Flow | 40 L/min |
| Hydraulic Pressure | 31 MPa |
| Crane Weight | 3,100 kg |
| Rotation Range | 360° full rotation |
| Stabilizer Extended Width | 5,608 mm |
| 10. Other Standard Features | |
| Hydraulic System | Complete hydraulic assembly |
| Control System | Dual side control hoods, wire remote control |
| Lighting | Light pylon in front of flatbed |
| Door Handles | Stainless steel door handles |
| 11. Standard Accessories | |
| Frame Fork | 4 sets of different size |
| Fork Adaptor | 1 set |
| Ratchet Strap Tie Down | 4 pieces |
| Towring Trolley | 2 pieces |
| Hook Chain | 2 pieces |
| 12. Shipping Specifications | |
| Shipping Size (L×W×H) | 10.5 × 2.5 × 3.75 m |
| Shipping Weight | 9,800 kg |
