ISUZU GIGA Water Spray Vehicle

Product Brief: ISUZU GIGA Water Spray Vehicle

The ISUZU GIGA Water Spray Vehicle is an advanced and versatile water tanker designed for efficient road spraying, dust suppression, firefighting, and agricultural irrigation. It is built on the ISUZU GIGA chassis, renowned for its durability and strength, and equipped with numerous features that make it suitable for a wide range of commercial and municipal applications. The vehicle boasts a sturdy construction, powerful engine, and multi-functional water spraying capabilities, ensuring optimal performance across various operational environments.

This model features the single-axle ISUZU GIGA cab, equipped with a half-cab design that allows for comfort and functionality. The GIGA series has been known for its ruggedness and adaptability, making it an excellent choice for heavy-duty tasks such as water transportation. The water tank is uniquely divided into multiple compartments to transport different types of liquids simultaneously, ensuring both efficiency and safety in transporting fluids.

---

Key Features of the ISUZU GIGA Water Spray Vehicle

1. Cabin Design and Chassis

• ISUZU GIGA Single-Axle Half-Cab Design: The ISUZU GIGA cab is a single-axle, half-cabin model, designed for optimal space and functionality. The cab is ergonomically designed for long hours of operation, providing comfort and convenience for the driver. It comes with standard features like a multifunctional steering wheel, electric windows, remote key entry, air conditioning, and air brake system, which enhance the overall driving experience.
• Durable Construction: The robust chassis design ensures longevity and can handle heavy loads with ease, making it perfect for operations that involve transporting large volumes of water or other liquids.

2. Engine and Transmission

• ISUZU 240 HP Engine: The vehicle is powered by a 240-horsepower ISUZU engine, which ensures smooth and efficient performance even under heavy loads. The engine is optimized for fuel efficiency and meets the stringent China VI (Euro VI equivalent) emission standards, making it environmentally friendly.
• Eight-Speed Manual Transmission: Paired with an eight-speed manual transmission, the vehicle allows precise control over speed and power, ensuring a smooth driving experience in various road conditions.
• Gear Ratio: The primary reduction ratio of 4.555 provides excellent torque and acceleration, making it easier to handle steep terrains and heavy loads.

3. Tires and Axle Configuration

• Tire Specifications: The ISUZU GIGA Water Spray Vehicle is equipped with durable steel radial tires, sized 295/80R22.5 16PR. These tires offer superior traction, enhanced load-bearing capacity, and improved longevity, ensuring that the vehicle can operate efficiently in rough or off-road conditions.
• Axle Configuration: The single-axle setup is ideal for managing heavy loads while maintaining maneuverability in urban or industrial environments.

4. Water Tank Design and Capacity

• Tank Structure: The water tank is designed in a square-round shape, which optimizes both capacity and stability. It is divided into three internal compartments, allowing for the transportation of different liquids without mixing. Each compartment is fitted with anti-wave baffles placed every 1.5 meters, which prevent liquid sloshing during transit. This feature enhances the vehicle’s stability and safety, especially when moving at high speeds or on uneven terrain.
• Tank Capacity: The vehicle has a gross weight rating of 18 tons, making it suitable for transporting significant volumes of water. The tank has a large capacity to carry enough liquid for extended operations such as road cleaning, irrigation, or firefighting.

5. Filling and Discharge Systems

• Multiple Water Inlets: The top of the water tank is fitted with three water inlets, making it easy and convenient to fill the tank. These inlets are strategically positioned to allow for quick water intake, reducing downtime during refills.
• Suction and Discharge Capabilities: The vehicle is equipped with self-priming and self-draining systems, which enable it to efficiently pump water in and out without external assistance. This feature is crucial for firefighting, agricultural irrigation, or dust suppression activities where quick access to water is required.

6. Spray System and Functions

• Multi-Functional Spray Nozzles: The ISUZU GIGA Water Spray Vehicle comes with front spray, rear spray, and side spray nozzles for versatile operations. These nozzles are ideal for road cleaning, dust suppression, and irrigation. The nozzles can be adjusted to spray water at different angles and pressures, depending on the requirement.
• Water Cannon: The vehicle is also equipped with a high-powered water cannon mounted at the rear, which can be used for long-distance spraying. This water cannon is perfect for tasks like firefighting or watering trees in hard-to-reach areas.
• High-Level Sprinkler: For irrigating tall trees or washing high walls, the vehicle has a high-position sprinkler located at the rear top of the tank. This feature adds to the vehicle’s versatility and ensures that no area is left unreachable.
• Compartmentalized Flow Control: The tank’s three internal compartments are each fitted with stainless steel ball valves, which allow the driver to control the flow of water from each section independently. This system ensures efficient usage of water, especially when different types of liquids are being transported.
• Firefighting Interface: The vehicle also comes with a fire hydrant interface and inlet valves, all neatly stored within a lockable toolbox. These features provide an added level of functionality, enabling the vehicle to be used in emergency situations.

7. Additional Features

• Convenient Storage: Suction hoses are stored in tubular storage compartments mounted on the sides of the tank. When not in use, these hoses are safely locked away, ensuring they do not fall off during transit.
• Customizable Appearance: The vehicle is painted in a standard white color, providing a clean and professional look. However, the exterior can be customized with different colors and designs to meet specific preferences or corporate branding requirements.

8. Safety and Operational Ease

• Air Brake System: The vehicle is equipped with an air brake system that ensures reliable stopping power, especially when operating under heavy loads. This system enhances overall safety, particularly during emergency stops.
• Remote Key and Electric Windows: The ISUZU GIGA Water Spray Vehicle comes with remote key entry and electric windows, offering modern convenience and ease of operation for the driver.
• Ergonomically Designed Cab: The cab features a well-laid-out instrument panel, providing the driver with easy access to all essential controls. Air conditioning and power steering further enhance driver comfort, reducing fatigue during long hours of operation.

---

The ISUZU GIGA Water Spray Vehicle is an ideal solution for municipalities, construction sites, agricultural fields, and firefighting departments. Its powerful engine, versatile spraying system, and large water tank ensure efficient performance across a range of applications. With multiple spray modes, a robust chassis, and advanced safety features, this vehicle stands out as a reliable choice for those who need a heavy-duty water transport and spraying solution.



SPECIFICATIONS:



Category	Specification
Cabin Model	ISUZU GIGA Single-Axle Half-Cab
Standard Features	Multifunctional Steering Wheel, Electric Windows, Remote Key, Air Conditioning, Air Brake System
Engine	ISUZU 240 HP, EURO VI Emission Standard
Transmission	8-Speed Manual
Gear Ratio	4.555
Tire Size	295/80R22.5 16PR Steel Radial Tires
Gross Vehicle Weight	18 Tons
Tank Design	Square-Round Tank, Divided into Three Compartments
Anti-Wave Baffles	Installed Every 1.5 meters inside the tank
Tank Capacity	Large Capacity for Multi-Liquid Transport
Water Inlets	3 Water Inlets on Top of the Tank
Spray Functions	Front Spray, Rear Spray, Side Spray, High-Powered Water Cannon
Self-Priming/Self-Draining	Yes
High-Level Sprinkler	Installed for High Tree Irrigation
Flow Control Valves	3 Stainless Steel Ball Valves for Independent Flow Control
Fire Hydrant Interface	Available, with Lockable Toolbox
Suction Hose Storage	Tubular Storage Compartments with Lock Mechanism
Paint Color	Standard White (Customizable)
Tire Storage	Side-Mounted Cannon Storage for Suction Hoses
Brake System	Air Brake System
Driver Comfort Features	Power Steering, Air Conditioning, Remote Key, Multifunctional LCD Display
High-Powered Water Cannon	Installed at Rear for Long-Distance Spraying
Firefighting Interface	Available for Emergency Situations
Overall Dimensions	Not provided in initial specifications
