ISUZU 22 CBM Bulk Feed Truck
The ISUZU 22 CBM Bulk Feed Truck is a highly efficient feed transportation solution designed for modern livestock farms, poultry operations, feed processing companies, and agricultural logistics providers. Built on a reliable ISUZU GIGA chassis, this vehicle combines large-volume feed storage, rapid unloading capability, and dependable road performance, making it an ideal choice for transporting bulk feed safely and efficiently over both short and long distances.
Featuring a 22 CBM feed tank with multiple internal compartments, the truck allows different types of feed materials to be transported simultaneously while preventing cross-contamination. The advanced hydraulic auger unloading system significantly improves unloading efficiency and reduces labor requirements, helping operators deliver feed directly into silos, storage bins, or feeding systems with minimal waste.
Powered by a 200 HP Euro 6 diesel engine, the truck delivers excellent fuel economy, strong torque output, and reliable performance under demanding operating conditions. Combined with a durable chassis structure, spacious sleeper cab, and advanced safety systems, the vehicle is engineered to provide long-term productivity and dependable service in the agricultural transportation industry.
Features
Large-Capacity 22 CBM Feed Tank
The tank truck is equipped with a 22 cubic meter bulk feed tank manufactured from high-quality Q235B carbon steel, providing excellent structural strength and durability. The horizontal cylindrical tank design maximizes storage efficiency while maintaining vehicle stability during transportation.
The tank can be configured with three compartments as standard, with an optional four-compartment arrangement available to accommodate different feed types, including poultry feed, livestock feed, aquatic feed, and grain powder.
Efficient Hydraulic Auger Unloading System
The advanced hydraulic auger conveyor system enables fast and controlled feed discharge directly into storage facilities or feeding equipment. Powered by a PTO-driven hydraulic pump, the unloading system offers a discharge capacity of 500–800 kg per minute, significantly reducing unloading time and improving operational efficiency.
The 7.5-meter auger with a diameter of 168 mm provides a working height of up to 8.5 meters and a horizontal reach of up to 6.5 meters, allowing operators to access a wide range of unloading positions with ease.
Reliable ISUZU Chassis Performance
Built on a durable 4×2 left-hand-drive chassis with a 5,600 mm wheelbase, the ISUZU truck offers excellent driving stability and load-carrying capability. The vehicle is powered by the YUCHAI YCS04200-68 Euro 6 engine, generating 200 horsepower and 720 N.m of torque, ensuring smooth operation even when transporting full loads.
The matching manual transmission with 5 forward gears and 1 reverse gear delivers dependable power transfer while maintaining fuel efficiency during daily operations.
Enhanced Safety and Driver Comfort
The truck comes equipped with a range of safety features, including a dual-circuit pneumatic air brake system, ABS, spring parking brake, and engine exhaust brake, helping ensure safe operation under various road conditions.
Inside the ISUZU GIGA single sleeper cab, operators benefit from air conditioning, power steering, ergonomic controls, and a comfortable driving environment that helps reduce fatigue during long-distance transportation.
Practical Tank Accessories and Maintenance-Friendly Design
To improve operational convenience, the tank is equipped with European-standard manholes, a heavy-duty lockable toolbox, anti-slip top walkway, foldable safety handrails, rear access ladder, mechanical feed level indicator, safety valve, and inspection ports.
These practical features simplify inspection, loading, unloading, and maintenance procedures while enhancing overall workplace safety.
Durable Surface Treatment and Corrosion Protection
The entire vehicle undergoes professional shot blasting and surface pre-treatment before assembly. The tank body is sandblasted to improve coating adhesion, while internal surfaces receive anti-corrosion treatment for extended service life.
A high-performance epoxy primer and advanced polyurethane topcoat provide outstanding resistance to weather, corrosion, and daily wear, helping maintain the truck’s appearance and durability even in demanding agricultural environments.
Specification
| ISUZU 22 CBM Bulk Feed Truck Technical Specifications | |
| Item | Specification |
| Vehicle Model | ISUZU 22 CBM Bulk Feed Truck |
| Drive Type | 4×2 LHD |
| Overall Dimensions (L×W×H) | 9,850 × 2,500 × 3,980 mm |
| Gross Vehicle Weight (GVW) | 18,000 kg |
| Curb Weight | 8,500 kg |
| Payload Capacity | 9,300 kg |
| Tank Volume | 22 CBM |
| Wheelbase | 5,600 mm |
| Cab | ISUZU GIGA Single Sleeper Cab, A/C, Power Steering |
| Engine | YUCHAI YCS04200-68, Euro 6 |
| Engine Power | 200 HP (147 kW) |
| Engine Type | 4-Cylinder, Turbocharged, Intercooled Diesel |
| Maximum Torque | 720 N.m |
| Transmission | Manual, 5 Forward + 1 Reverse |
| Transmission Brand | ISUZU |
| Tires | 295/80R22.5, 18PR |
| Number of Tires | 6 + 1 Spare |
| Front Axle Capacity | 6.5 Ton |
| Rear Axle Capacity | 11.5 Ton |
| Clutch | Single Plate Dry Clutch |
| Brake System | Dual-Circuit Pneumatic Air Brake |
| Parking Brake | Spring Energy Parking Brake |
| Auxiliary Brake | Engine Exhaust Brake |
| ABS | Equipped |
| Electrical System | 24V |
| Battery | 2 × 12V, 120Ah |
| Fuel Tank Capacity | 200 L Aluminum Alloy Fuel Tank |
| Tank Material | High-Quality Carbon Steel (Q235B) |
| Tank Thickness | 4 mm Tank Body / 5 mm End Plate |
| Tank Shape | Horizontal Cylindrical with Internal Compartments |
| Feed Compartments | 3 Compartments (Optional 4 Compartments) |
| Medium Transported | Poultry Feed, Livestock Feed, Aquatic Feed, Grain Powder |
| Bulk Density Reference | 0.5 – 0.8 t/m³ |
| Loading Method | Top Feeding through Manholes |
| Discharge Method | Hydraulic Auger Unloading System |
| Auger Diameter | 168 mm |
| Auger Length | 7.5 m |
| Discharge Speed | 500 – 800 kg/min |
| Hydraulic System Drive | PTO Driven Hydraulic Pump |
| Working Height of Auger | Up to 8.5 m |
| Horizontal Reach | Up to 6.5 m |
| Manhole | 3 pcs, European Standard Manholes |
| Toolbox | 1 pc Heavy-Duty Lockable Toolbox |
| Cat Walkway | Anti-Skid Steel Plate Walkway Installed on Tank Top |
| Handrail | Foldable Safety Handrails on Both Sides |
| Ladder | Rear Climbing Ladder with Safety Protection |
| Level Indicator | Mechanical Feed Level Indicator |
| Safety Valve | Equipped |
| Inspection Port | Equipped |
| PTO (Power Take-Off) System | Standard Equipped |
| Hydraulic Oil Tank | Standard Equipped |
| Hydraulic Pump and Motor | Standard Equipped |
| Hydraulic Auger Conveyor System | Standard Equipped |
| Feed Discharge Control System | Standard Equipped |
| Air Conditioning | Standard Equipped |
| Power Steering | Standard Equipped |
| Reverse Alarm | Standard Equipped |
| Reflective Safety Markings | Standard Equipped |
| Wheel Chocks | Standard Equipped |
| Fire Extinguisher | Standard Equipped |
| Basic Tool Kit | Standard Equipped |
| Surface Pre-Treatment | Entire vehicle shot-blasted and pre-treated before assembly; Tank body sandblasted for enhanced coating adhesion |
| Internal Tank Protection | Internal tank surfaces treated with anti-corrosion protection |
| Coating System | High-performance epoxy primer applied before painting; Advanced polyurethane topcoat finish with excellent weather resistance and durability |
| Customization Option | Customer logo, color scheme, and branding available upon request |
