ISUZU 60M Aerial Ladder Fire Truck
The ISUZU 60M Aerial Ladder Fire Truck is a high-performance emergency rescue vehicle designed for high-rise firefighting, industrial rescue, and complex aerial operation missions where maximum reach, stability, and reliability are required. Built on the heavy-duty Qingling ISUZU QL5350JQFRTY GIGA 8×4 fire chassis, this vehicle combines strong carrying capacity, advanced aerial ladder technology, and professional firefighting equipment to provide firefighters with a safe and efficient solution for elevated rescue operations.
Equipped with a 60-meter aerial ladder system, the truck is capable of reaching high-rise buildings, industrial towers, warehouses, and large-scale public facilities where traditional firefighting equipment cannot provide sufficient access. The advanced boom structure delivers a maximum working height of 60 meters and a working reach of up to 18 meters, allowing rescue teams to perform personnel evacuation, fire suppression, and emergency support operations from elevated positions.
The vehicle is powered by the reliable ISUZU 6UZ1-TCG61 Euro VI diesel engine, producing 380 HP and 1,800 N·m of torque, ensuring strong power output even under heavy-duty operating conditions. The engine is matched with a 12-speed manual transmission and a reinforced 8×4 drivetrain, providing excellent mobility while carrying a large aerial system and firefighting equipment.
The ISUZU GIGA chassis features a reinforced frame structure, heavy-duty suspension, powerful braking system, and large-capacity fuel system, making it suitable for long-distance emergency deployment and continuous operation. The vehicle adopts a spacious double crew cab, allowing multiple firefighters to travel together with necessary rescue equipment.
With its combination of high aerial capability, powerful chassis performance, and professional firefighting configuration, the ISUZU aerial ladder fire truck is an ideal choice for fire departments, industrial emergency teams, airports, and municipal rescue organizations requiring dependable high-rise firefighting solutions.
Features
Powerful Qingling ISUZU GIGA 8×4 Fire Chassis
The truck is built on the Qingling ISUZU QL5350JQFRTY heavy-duty firefighting chassis, specially configured to support large aerial equipment while maintaining excellent driving stability and operational safety.
Chassis Specifications
- Chassis Manufacturer: Qingling ISUZU
- Chassis Model: QL5350JQFRTY
- Drive Type: 8×4 Left-Hand Drive
- Cab Type: ISUZU GIGA Double Crew Cab
- Crew Capacity: 2+4 Persons
- Wheelbase: 4,600 + 1,370 mm
- Gross Vehicle Weight: 31,000 kg
- Maximum Speed: 95 km/h
- Fuel Tank Capacity: 400 L Aluminum Alloy Fuel Tank
The reinforced chassis frame provides strong support for the aerial ladder system, while the 8×4 drive configuration ensures stable performance on highways, city roads, and emergency access routes.
High-Power ISUZU Engine and Reliable Drivetrain
The vehicle is equipped with the advanced ISUZU 6UZ1-TCG61 diesel engine, delivering excellent power output, durability, and fuel efficiency for demanding firefighting applications.
Engine Performance
- Engine Model: ISUZU 6UZ1-TCG61
- Manufacturer: Qingling ISUZU
- Engine Type: Inline 6-cylinder, turbocharged, intercooled, water-cooled diesel engine
- Displacement: 9.839 L
- Rated Power: 279 kW (380 HP)
- Maximum Torque: 1,800 N·m
- Emission Standard: Euro VI
The powerful engine provides sufficient torque for climbing slopes, transporting heavy rescue equipment, and operating the aerial ladder system through the full working range.
Transmission System
- Transmission: FAST 12-Speed Manual / ISUZU Matching
- Gearbox: 12 Forward + 2 Reverse
- Clutch: Hydraulic Assisted Single Dry Plate
- Steering: Hydraulic Power Steering
- PTO: Full Power Sandwich PTO
The optimized drivetrain ensures smooth power transmission and reliable operation during emergency deployment.
Advanced 60-Meter Aerial Ladder System
The core feature of this vehicle is its professional 60M aerial ladder system, which provides exceptional vertical access for high-rise rescue and firefighting operations.
Aerial Performance
- Rated Working Height: 60 meters
- Maximum Working Reach: 18 meters
- Boom Raising Time: ≤180 seconds
- Outrigger Deployment Time: ≤25 seconds
- Bucket Rated Load: 180 kg
- Bucket Lifting Speed: 0.8 m/s
- Bucket Working Angle: 45°–75°
The aerial ladder system is engineered for smooth movement, accurate positioning, and stable operation, allowing firefighters to safely reach elevated locations for rescue and firefighting tasks.
Efficient Firefighting Water Delivery System
The truck integrates a high-performance firefighting pump and monitor system designed for rapid fire suppression in large-scale emergency situations.
Firefighting Equipment
- Fire Pump Flow Rate: ≥4,800 L/min
- Fire Monitor Range: ≥70 meters
The high-capacity pump system provides strong water delivery performance, while the long-range monitor enables effective firefighting from a safe distance, making the vehicle suitable for industrial facilities, high-rise buildings, and large public areas.
Heavy-Duty Suspension and Safety Systems
To ensure stability during aerial operations, the truck is equipped with reinforced suspension and advanced braking technology.
Chassis Safety Configuration
- Front Suspension: Heavy-duty multi-leaf spring suspension with shock absorbers
- Rear Suspension: Reinforced multi-leaf spring suspension
- Brake System: Full air dual-circuit brake
- ABS: Equipped
- Parking Brake: Spring energy brake
- Auxiliary Brake: Engine exhaust brake
The suspension and braking systems improve vehicle control, especially when carrying heavy firefighting equipment and operating under emergency conditions.
Durable Tires and Electrical System
The vehicle uses heavy-duty components designed for long service life and reliable operation.
Supporting Configuration
- Tire Size: 315/80R22.5 Steel Radial Tires
- Tire Quantity: 12 + 1 Spare Tire
- Electrical System: 24V
The large-size tires provide excellent load-bearing ability and road adaptability, while the 24V electrical system ensures stable operation of warning lights, communication equipment, and firefighting accessories.
Professional Emergency Rescue Capability
Designed for modern firefighting requirements, the ISUZU 60M Aerial Ladder Fire Truck provides a complete solution for high-rise rescue, industrial firefighting, and emergency response missions. Its combination of the ISUZU GIGA chassis, a powerful diesel engine, a high-reach aerial ladder, and a large-capacity firefighting system makes it a dependable choice for professional fire departments and rescue organizations worldwide. Along with other specialized vehicles such as fire truck, aerial rescue equipment, and municipal emergency vehicles from ISUZU Vehicles, this model demonstrates strong adaptability for different firefighting and disaster response environments.
Specifications
| Item | Specification |
|---|---|
| Chassis Manufacturer | Qingling ISUZU |
| Chassis Model | QL5350JQFRTY (ISUZU GIGA Fire Fighting Chassis) |
| Drive Type | 8×4 Left-Hand Drive |
| Cab | ISUZU GIGA Double Crew Cab |
| Passengers | 2+4 Persons |
| Wheelbase | 4,600 + 1,370 mm |
| Overall Chassis Dimensions (Approx.) | 11,200 × 2,500 × 3,150 mm |
| Gross Vehicle Weight (GVW) | 31,000 kg |
| Curb Weight (Chassis) | Approx. 11,800 kg |
| Front Axle Capacity | 7,500 kg ×2 |
| Rear Axle Capacity | 13,000 kg ×2 |
| Fuel Tank Capacity | 400 L Aluminum Alloy Fuel Tank |
| Maximum Speed | 95 km/h |
| Engine Manufacturer | Qingling ISUZU |
| Engine Model | ISUZU 6UZ1-TCG61 |
| Engine Type | Inline 6-cylinder, Turbocharged, Intercooled, Water-cooled Direct Injection Diesel |
| Displacement | 9.839 L |
| Rated Power | 279 kW (380 HP) |
| Maximum Torque | 1,800 N·m |
| Emission Standard | Euro VI |
| Transmission | FAST 12-Speed Manual / ISUZU Matching |
| Gearbox | 12 Forward + 2 Reverse |
| Clutch | Hydraulic Assisted Single Dry Plate |
| Steering | Hydraulic Power Steering |
| PTO | Full Power Sandwich PTO |
| Front Suspension | Heavy-duty Multi-Leaf Spring Suspension with Shock Absorbers |
| Rear Suspension | Reinforced Multi-Leaf Spring Suspension |
| Brake System | Full Air Dual-Circuit Brake |
| ABS | Equipped |
| Parking Brake | Spring Energy Brake |
| Auxiliary Brake | Engine Exhaust Brake |
| Tire Size | 315/80R22.5 Steel Radial Tires |
| Tire Quantity | 12 + 1 Spare |
| Electrical System | 24V |
| Overall Length | 13,620 mm |
| Overall Width | 2,500 mm |
| Overall Height | 4,000 mm |
| Gross Vehicle Weight | 30,550 kg |
| Curb Weight | 30,400 kg |
| Maximum Driving Speed | 95 km/h |
| Engine Rated Power | 279 kW (380 HP) |
| Rated Working Height | 60 m |
| Maximum Working Reach | 18 m |
| Boom Raising Time | ≤180 s |
| Outrigger Deployment Time | ≤25 s |
| Fire Pump Capacity | ≥4,800 L/min |
| Fire Monitor Range | ≥70 m |
| Bucket Rated Load | 180 kg |
| Bucket Lifting Speed | 0.8 m/s |
| Bucket Working Angle | 45°–75° |
