ISUZU 8000L Water Fire Truck

ISUZU 8000L Water Fire Truck

The ISUZU 8000L Water Fire Truck is a professional medium-duty firefighting vehicle designed for municipal fire departments, industrial facilities, warehouses, commercial properties, construction sites, and other emergency-response applications where a reliable onboard water supply and long-range firefighting capability are required. Built on the dependable ISUZU FVR chassis, the truck combines an 8,000-liter water tank with a CB10/40 fire pump and PS40 fire monitor, providing a practical balance between water-carrying capacity, maneuverability, and firefighting performance.

The vehicle has overall dimensions of approximately 8,230×2,500×3,350mm, with a 4,600mm wheelbase and a GVW of approximately 18,000kg. Its 4×2 drive configuration, 11.00-20 tires, ABS, and crew cab provide a stable and practical platform for emergency transportation, while the maximum driving speed of approximately 90km/h allows the truck to respond efficiently to fire scenes.

Power is supplied by an ISUZU 4HK1-TC50 diesel engine producing approximately 190HP and meeting the Euro 5 emission standard. The vehicle is equipped with a CB10/40 fire pump with a rated capacity of 40L/s and a PS40 fire monitor, providing a high-volume firefighting stream for attacking fires from a suitable distance.

The crew cab is configured to accommodate two front-line crew members and four rear-line crew members, allowing a complete firefighting team to travel with the vehicle and begin operations quickly after arriving at the emergency location.

Features

1. Reliable ISUZU FVR Chassis

The truck is built on an ISUZU FVR chassis, featuring a 4×2 drive configuration, two axles, and a 4,600mm wheelbase, providing a strong and maneuverable foundation for the 8,000-liter firefighting body.

With a GVW of approximately 18,000kg and six 11.00-20 tires, the chassis is designed to carry the water tank and firefighting equipment while maintaining stable road performance. ABS is also equipped to provide additional braking control during emergency response.

2. 8,000L Water Tank

The vehicle is equipped with an 8,000L water tank, providing a substantial onboard water reserve for firefighting operations in locations where an external water supply may not be immediately available.

The capacity is well suited to municipal firefighting, industrial facilities, warehouses, workshops, commercial buildings, and construction areas, allowing firefighters to begin suppression immediately after arrival instead of waiting for an external water connection.

3. 190HP ISUZU Diesel Engine

The truck is powered by an ISUZU 4HK1-TC50 engine producing approximately 190HP and complying with the Euro 5 emission standard.

The diesel engine provides sufficient power for emergency transportation while carrying a substantial water load, and its heavy-duty configuration makes the vehicle suitable for repeated operation in demanding firefighting and municipal service environments.

4. CB10/40 High-Flow Fire Pump

The firefighting system incorporates a CB10/40 fire pump with a rated flow capacity of approximately 40L/s, providing a strong and continuous supply of water from the onboard tank to the fire monitor and hose equipment.

The pump’s high flow rate allows the crew to deliver a substantial volume of water during active suppression, making the system suitable for both initial attack and sustained firefighting operations.

5. PS40 Fire Monitor

A PS40 fire monitor is installed as the primary long-range water discharge device, enabling firefighters to direct a concentrated water stream toward the fire without needing to position personnel directly beside the flames.

The supplied specifications indicate a fire range of up to approximately 250 meters, giving the truck a significant operational reach for large-area firefighting and emergency water application.

6. Six-Person Crew Cab

The crew cab provides seating for the firefighting team, with two front-line crew positions and four rear-line crew positions, allowing up to six personnel to travel with the vehicle.

This configuration is particularly practical for fire departments that require firefighters to arrive together with the main firefighting equipment, reducing response time and allowing the team to establish the firefighting system immediately after reaching the incident.

7. Emergency Response Performance

The vehicle has a specified maximum driving speed of approximately 90km/h, allowing it to respond efficiently across urban roads, industrial areas, highways, and other emergency routes.

The combination of the ISUZU FVR chassis, 190HP engine, 4×2 drivetrain, ABS, and heavy-duty tires provides a practical balance between road mobility and firefighting payload, making the truck suitable for both short-distance municipal response and longer-distance emergency deployment.

8. Practical Firefighting Accessories

The truck is supplied with essential firefighting accessories, including suction hoses, water hoses, direct spray nozzles, and fire extinguishers, giving the crew additional options for localized firefighting and water delivery operations.

These accessories complement the main fire pump and monitor, allowing firefighters to adapt their equipment setup according to the size, location, and characteristics of the fire.

9. Complete Vehicle Documentation

The ISUZU 8000L Water Fire Truck is supplied with a comprehensive documentation package covering both the chassis and firefighting equipment, including the chassis operation manual, maintenance manual, chassis guarantee, chassis certification, engine number, VIN information, fire truck manual, accessories list, fire truck certification, service card, and receipt list.

The complete documentation package supports proper vehicle operation, routine maintenance, equipment management, and after-sales service throughout the truck’s working life.

10. Suitable for Municipal and Industrial Fire Protection

With its combination of an 8,000L water tank, 40L/s fire pump, PS40 fire monitor, 190HP ISUZU engine, and crew cab, the ISUZU 8000L Water Fire Truck provides a practical firefighting solution for organizations that require a dependable water-supply fire engine with professional emergency equipment.

The vehicle is particularly suitable for municipal fire departments, factories, warehouses, logistics centers, workshops, commercial buildings, construction projects, and industrial facilities, where rapid response, reliable water delivery, and flexible firefighting capability are essential.

Specifications

ITEM	VALUE
Chassis Model Line/Number	FVR
Chassis Manufacturer	ISUZU
Overall Size	8,230×2,500×3,350mm
Water Tank Capacity	8,000L
GVW	18,000kg
Wheelbase	4,600mm
Cabin	Crew Cab
Approach/Departure Angle	18°/18°
ABS	Equipped
Front line Crew	2 nos
Rear Line Crew	4 nos
Fire Pump – Model	CB10/40
Fire Pump – Capacity	40L/S
Fire Monitor	PS40
Fire Range	250m
Engine – Model Number	4HK1-TC50
Engine – Emission Class Level	Euro 5
Engine – Fuel Type	Diesel
Drive Mode	4×2
Chassis Truck – Model Number	QL1180VMFRY
Chassis Truck – Axle Numbers	2
Chassis Truck – Tire Numbers	6 (11.00-20)
Chassis Truck – Max. Driving Speed	90km/h
Chassis Truck – Wheelbase	4,600mm
Chassis Truck – Manufacturer	ISUZU
Engine Power	190hp
Documents	Chassis Operation Manual, Chassis Maintenance Manual, Chassis Guarantee, Chassis Certification, Tool Kits List, Engine Number, VIN Number, Fire Truck Manual, Fire Truck Accessories List, Fire Truck Certification, Service Card, Receipt list
Accessories – Suction Hose	NOS
Accessories – Water Hose	NOS
Accessories – Direct Spray Nozzle	NOS
Accessories – Extinguishers	NOS
