Introduction:
With over 60 years of experience in the special vehicle industry, ISUZU has emerged as a leading supplier of a wide range of fire trucks. Our offerings include water fire trucks (the conventional blister fire truck), water and foam fire trucks, dry powder fire trucks, fire ladder trucks, airport rescue firefighting trucks, combination rescue trucks, and more. Only through the perfect integration of chassis and superstructure can a fire engine be truly effective, and we excel in achieving this balance!
Application:
Water and foam fire trucks represent the most commonly utilized vehicles in fire brigades, boasting high efficiency in residential areas, warehouses, industrial facilities, and highways. These trucks are specifically designed to extinguish fires of various classifications:
- Gas fire: Class C.
- Flammable liquids fire: Class B.
- Solid substances fire: Class A.
Structure:
Similar to other water and foam fire trucks, the ISUZU water and foam fire truck comprises a chassis, superstructure, power take-off (PTO), water tanker, foam tanker, pump room, foam proportional mixing device, fire monitor, and more.
Performance of Chassis:
- Equipped with an ISUZU chassis featuring 4X4 four-wheel drive capability.
- With this robust chassis, the vehicle is prepared to tackle any challenge, anywhere.
- Despite its power, the truck offers exceptional comfort and driving characteristics.
- The chassis is constructed with high-strength steel, ensuring durability and reliability.
SPECIFICATIONS:
General | |||
Brand | ISUZU | ||
Overall dimension | 8490×2530×3550mm | ||
GVW | 19300KG | ||
Tare weight | 5090kg | ||
Emission standard | Euro5 | ||
Front/Rear overhang | 1335/1735mm | ||
Leaf Spring | 8/6+5 | ||
High speed | 95km/h | ||
Chassis | |||
Make | ISUZU | ||
Model | ISUZU QL2160VMFRY | ||
Fuel type | Diesel | ||
Drive Type | 4×4 | ||
Wheelbase | 4500mm | ||
Front/Rear track | 1960/1855mm | ||
Tyre specs | 10.00R20 16PR, 11.00R22.5 16PR | ||
Tyre No. | 6+1 | ||
Front axle loading | 6300kg | ||
Rear axle loading | 13000kg | ||
Engine | |||
Brand | ISUZU | ||
Mode | 4HK1-TC50 | ||
Cylinder | Inline 4-cylinders, | ||
Output power | 151kw | ||
Max horsepower | 205hp | ||
Output torque/speed | 650N.m/1500rpm | ||
Gearbox | ISUZU MLD | ||
Control type | Manually | ||
Displacement | 5.193L | ||
Gear No. | 5 forward+1 reverse | ||
Cab(Crew) | |||
Seat No | 2+4 | ||
Air conditioner | optional | ||
Color | Red or optional | ||
A refrigerated box in the cabin. | |||
The floor covering is non-slip and washable. | |||
Internal roll bar. | |||
Respiratory protection system in case of distress when a fire front passes over the vehicle. | |||
Water tank | |||
Material | Stainless material | ||
Structure | Crew cab with 4 doors | ||
Water tanker Capacity | 5000L | ||
Others | 1 manhole+1 pressure relief device+1 indicator of liquid level+1 outlet with valve | ||
The interior of the tank is designed in such a way as to ensure the balancing of the means during maneuvers. | |||
Protection against overflow: No water loss in the event of a full tank and an inclination/slope ≤ 30° | |||
Foaming agent | |||
Capacity | 1000L | ||
Material | Stainless material | ||
Others | Pressure level indicator. | ||
Foam concentrate tank filling level indicator. | |||
Drain valve | |||
Water pump | |||
Brand | Shanghai RONGSHEN | ||
Model | CB10/60 | ||
Rated flow | 20L/[email protected] | ||
Pressure | 1.0MPa | ||
Fire monitor | |||
Brand | Chengdu WST | ||
Model | PS48 | ||
Rated flow | 48L/S | ||
Range | >50m | ||
Working Pressure | <0.7MPa | ||
pitch rotation angle | -30~+70(°) | ||
Horizontal Rotation | 0~360(°) | ||
Weight | ≤25kg | ||
Electric system | |||
Auxiliary lighting | Lighting lamps, and the control panel is equipped with lighting, indicator lights, etc. | ||
Strobe lights | Red and blue strobe lights on both sides of the vehicle. | ||
Firefighting light | 35W fire searchlight installed on the rear of the bodywork | ||
Warning device | Long row red warning lights installed on the top of the cab | ||
The control box for the siren is located in the front of the driver. | |||
List of document carried in the vehicle | |||
No. | Name | Specification | Qty |
1 | Water pipe(snap type) | Φ100x2m | 4 |
2 | Water filter(snap type) | FLF100 | 1 |
3 | Water segregator | FII80/65×2-1.6 | 1 |
4 | Manifold converging | JII1100/65×2-1.0 | 1 |
5 | Fire hose(Insertion type) | 13-65-20 | 6 |
6 | Fire hose(Insertion type) | 3-80-20 | 4 |
7 | Injection Fire hose | 13-65-5 | 1 |
8 | Irregular onterface | 65/80 | 1 |
9 | Hose bandage | DT-SB | 4 |
10 | Hose hook | 4 | |
11 | Ground fire hydrant wrench | QT-DS1;400 long | 1 |
12 | Underground hydrant wrench | 860 long | 1 |
13 | Water pipe wrench | FS100 | 2 |
14 | Multifunction water spear | QZG3.5/7.5;65 | 1 |
15 | Multifunction water spear | QHD3.5/7.5;65 | 1 |
16 | Fire extinguisher | 3 kg/ABC | 1 |
17 | Fire ax | QTF-PF; 810mm | 1 |
18 | Fire waist ax | GF-285;390mm | 1 |
19 | Rubber hammer | 1 |
