ISUZU 10 CBM Hook Lift Garbage Truck
The ISUZU 10 CBM Hook Lift Garbage Truck is a versatile and efficient waste collection vehicle designed for modern municipal sanitation systems, residential waste management, and industrial waste transportation. Built on the reliable ISUZU 700P 4×2 chassis, this truck combines durability, operational flexibility, and efficient hydraulic lifting technology to support a wide range of waste collection and container transport operations.
Powered by the proven ISUZU 4HK1-TCG40 turbocharged diesel engine, the truck delivers 190 horsepower and 510 N·m of torque, providing dependable power for both transportation and hydraulic lifting operations. With a displacement of 5.193 liters and a high-pressure common rail fuel system, the engine ensures strong fuel efficiency while maintaining compliance with Euro V emission standards, making the vehicle suitable for urban sanitation operations and municipal fleets.
The truck features a well-balanced structural design with overall dimensions of 7,200 × 2,300 × 2,900 mm and a wheelbase of 4,175 mm, providing stable driving performance and maneuverability on narrow city streets and residential areas. With a gross vehicle weight of 11,000 kg and a rated payload capacity of 6,300 kg, the truck is capable of handling large waste containers while maintaining efficient operational performance.
At the core of its functionality is a 10 cubic meter detachable garbage container, which can be quickly loaded, transported, and unloaded using the integrated hydraulic hook lift system. This system allows one truck to operate with multiple containers, significantly improving waste collection efficiency and reducing operational downtime. The vehicle is therefore an ideal solution for municipal sanitation departments, environmental service companies, and urban waste management operations that require flexible and cost-effective waste handling equipment.
Key Features
Reliable ISUZU Powertrain
The truck is equipped with the ISUZU 4HK1-TCG40 inline four-cylinder turbocharged diesel engine, which is widely recognized for its durability and fuel-efficient performance in medium-duty commercial vehicles. With a maximum output of 139 kW (190 HP) and strong torque delivery, the engine ensures stable operation even when the vehicle is carrying fully loaded containers.
The powertrain is paired with the ISUZU MLD-6 manual transmission, offering six forward gears and one reverse gear, which allows operators to select appropriate gear ratios for various driving conditions. This configuration provides smooth gear shifting, efficient fuel consumption, and reliable power delivery during daily sanitation operations.
High-Capacity 10 CBM Detachable Container
The truck utilizes a 10 CBM garbage container constructed from high tensile wear-resistant carbon steel, ensuring excellent durability and resistance to deformation during heavy-duty waste transportation. The container features 4 mm thick steel plates on the sides and top, with a reinforced 4 mm bottom, providing additional strength for long-term operation.
The container design supports both underground and aboveground waste collection systems, making the truck suitable for a wide range of municipal waste management applications. A reinforced container frame structure further improves stability during loading and unloading operations.
For enhanced operational flexibility, the system allows one truck to operate with multiple containers, enabling sanitation teams to place several containers at different collection points while using a single vehicle for transportation.
Efficient Hydraulic Hook Lift System
The truck is equipped with a PTO-driven hydraulic hook lift system, which enables fast and efficient loading and unloading of waste containers. The hydraulic system includes two lifting cylinders and two landing leg cylinders, which work together to smoothly raise, transport, and position the container during operation.
To ensure stable performance and safety, the system incorporates dual balance valves, which help maintain smooth and controlled movement of the lifting arms during operation. The hydraulic system is powered by a high-pressure gear pump, ensuring reliable hydraulic pressure for consistent lifting performance.
The container handling process is highly efficient, with a loading time of approximately 30 seconds and an unloading time of about 50 seconds, significantly improving operational productivity during daily waste collection tasks.
Durable Chassis and Suspension Structure
The vehicle is built on the robust ISUZU 700P chassis, which is specifically engineered to support medium-duty sanitation and logistics equipment. The chassis features a front axle capacity of 4,000 kg and a rear axle capacity of 7,000 kg, ensuring balanced load distribution and stable driving performance even when the container is fully loaded.
The truck is equipped with 8.25R16 steel radial tires, providing strong load-bearing capability and reliable traction for both urban roads and construction site environments. A total of six tires plus one spare tire ensures operational reliability for long-term fleet use.
Comfortable and Practical Driver Cabin
The truck features the ISUZU ELF day cab, designed with a durable steel construction and a seating capacity for three occupants, including the driver and two passengers. The cabin is configured with right-hand drive, making it suitable for markets where this driving configuration is required.
To enhance driver comfort and operational convenience, the cabin includes air conditioning and an adjustable steering system, allowing operators to maintain comfort and control during extended working hours.
Safety and Operational Features
The vehicle is equipped with a full air braking system, which provides strong and reliable braking performance during both transportation and container handling operations. The spring energy parking brake ensures secure parking even when the truck is fully loaded, while ABS improves vehicle stability and safety during emergency braking situations.
Additional optional features such as a rear camera system, LED warning lights, and sealed container covers can further enhance operational safety and environmental protection. Customers may also select stainless steel containers depending on operational requirements, especially when transporting corrosive waste materials.
The ISUZU 10 CBM Hook Lift Garbage Truck offers a practical combination of efficient waste container handling, reliable ISUZU engineering, and flexible multi-container operation, making it a dependable and cost-effective solution for modern municipal sanitation and waste management services.
SPECIFICATIONS
| Item | Details |
|---|---|
| Chassis Brand | ISUZU |
| Chassis Model | ISUZU 700P |
| Drive Type | 4×2 |
| Overall Dimensions (L×W×H) | 7,200 × 2,300 × 2,900 mm |
| Wheelbase | 4,175 mm |
| Gross Vehicle Weight (GVW) | 11,000 kg |
| Curb Weight | 4,500 kg |
| Rated Payload | 6,300 kg |
| Maximum Speed | 100 km/h |
| Fuel Type | Diesel |
| Emission Standard | Euro V |
| Steering | Right-Hand Drive |
| Engine Brand | ISUZU |
| Engine Model | 4HK1-TCG40 |
| Engine Type | Inline 4-cylinder Turbocharged Intercooled Diesel |
| Displacement | 5.193 L |
| Maximum Power | 139 kW |
| Maximum Horsepower | 190 HP |
| Maximum Torque | 510 N·m |
| Fuel System | High Pressure Common Rail |
| Transmission Brand | ISUZU |
| Transmission Model | MLD-6 |
| Transmission Type | Manual |
| Gears | 6 Forward + 1 Reverse |
| Operation | Manual |
| Clutch Type | Dry Single Plate |
| Power Take-Off (PTO) | Equipped for hydraulic hook lift system |
| Cabin Type | ISUZU ELF Day Cab |
| Structure | Steel Construction |
| Seat Capacity | 3 Persons |
| Driving Position | Right-Hand Drive |
| Features | Air Conditioning, Adjustable Steering |
| Container Capacity | 10 CBM |
| Container Material | High Tensile Wear-Resistant Carbon Steel |
| Container Thickness | Side & Top 4 mm, Bottom 4 mm |
| Container Type | Underground & Aboveground Types Optional |
| Container Structure | Reinforced Frame |
| Container Locking | Hydraulic Locking Pins |
| Hydraulic Drive | PTO Driven |
| Hydraulic Cylinders | 2 Lifting Cylinders + 2 Landing Leg Cylinders |
| Balance Valves | Dual Balance Valves |
| Hydraulic Control | Manual Lever Control |
| Hydraulic Pump | High Pressure Gear Pump |
| Loading Time | ≤ 30 seconds |
| Unloading Time | ≤ 50 seconds |
| Front Axle Capacity | 4,000 kg |
| Rear Axle Capacity | 7,000 kg |
| Tire Size | 8.25R16 |
| Tire Type | Steel Radial |
| Number of Tires | 6 + 1 Spare |
| Fuel Tank Capacity | 120 L |
| Braking System | Full Air Brake |
| Parking Brake | Spring Energy Brake |
| ABS | Equipped |
| Stainless Steel Container | Optional |
| Sealed Container Cover | Optional |
| Multiple Containers | One Truck with Multiple Containers |
| Rear Camera | Optional |
| LED Warning Lights | Optional |
