ISUZU 8 Ton Hook Loader Garbage Truck

ISUZU 8 Ton Hook Loader Garbage Truck

The ISUZU 8 Ton Hook Loader Garbage Truck is a versatile and efficient waste transportation vehicle engineered to simplify container collection, transfer, and unloading for municipal sanitation departments, industrial parks, construction sites, and commercial waste management companies. Built on the dependable ISUZU 4×2 chassis, this hook lift truck combines outstanding payload capability with a powerful hydraulic lifting system, allowing a single vehicle to handle multiple detachable waste containers and significantly improve fleet utilization.

Powered by a reliable 205 HP ISUZU Euro 5 diesel engine, the truck delivers excellent fuel efficiency, dependable performance, and strong pulling power for demanding daily operations. Its hydraulic hook lift system enables quick container loading, secure transportation, and smooth tipping, reducing manual labor while improving operational safety and productivity. Designed for continuous heavy-duty service, the vehicle offers an ideal solution for modern refuse collection and containerized waste transportation.

---

Features

Reliable ISUZU Chassis Performance

Built on a durable ISUZU 4×2 chassis, the truck provides excellent stability, driving comfort, and load-carrying capability for intensive municipal and industrial applications.

Key chassis specifications include:

• Overall Dimensions: 7,300 × 2,480 × 2,990 mm
• Gross Vehicle Weight: 18,000 kg
• Curb Weight: 7,630 kg
• Wheelbase: 4,500 mm
• Front Axle Capacity: 6.3 tons
• Rear Axle Capacity: 13 tons

The optimized chassis design delivers dependable performance on both urban streets and industrial roads.

Powerful Euro 5 Diesel Engine

The garbage truck is equipped with the proven ISUZU 4HK1-TC50 diesel engine, providing reliable power and excellent fuel economy for demanding waste collection operations.

Engine highlights include:

• 205 HP output
• Turbocharged diesel engine
• Euro 5 emission standard
• Strong low-speed torque for heavy loads
• Stable performance during continuous operation

The engine is paired with an ISUZU MLD6 manual transmission featuring 6 forward gears and 1 reverse, ensuring smooth gear changes and efficient power delivery.

Heavy-Duty Hydraulic Hook Lift System

The hydraulic hook loader is designed for fast, safe, and efficient handling of detachable refuse containers, reducing loading time and increasing operational flexibility.

Performance specifications include:

• Maximum lifting and tipping capacity: 8 tons
• Hydraulic system pressure: 25 MPa
• Hook height: 1,295 mm
• Hook center to roller center distance: 3,255 mm
• Hydraulic system weight: 970 kg

The robust lifting mechanism provides smooth and reliable operation even under demanding working conditions.

Efficient Container Handling

Designed to accommodate a variety of detachable waste containers, the truck offers excellent adaptability for different waste collection tasks.

Key advantages include:

• Compatible with containers measuring 3.0–4.2 meters in length
• Fast container loading and unloading
• Secure transportation during road travel
• Reduced turnaround time between collection points

Using interchangeable containers allows one vehicle to serve multiple locations efficiently, improving overall fleet productivity.

Stable Tipping Performance

The hydraulic tipping system enables quick and controlled waste discharge at transfer stations or disposal facilities.

Key features include:

• 49° tipping angle for efficient unloading
• Smooth hydraulic operation
• Stable container positioning
• Reduced residual waste after discharge

This design helps shorten unloading cycles while minimizing operator effort.

Comfortable and Practical Cab

The spacious ISUZU cab is designed to provide a comfortable and productive working environment for daily operations.

Standard cab features include:

• Seating for 3 occupants
• Ergonomic driver controls
• Excellent forward visibility
• Comfortable interior layout
• Durable construction for commercial use

The operator-friendly design reduces fatigue during long working hours while improving driving safety.

Built for Municipal and Industrial Waste Management

Combining a dependable ISUZU chassis, a fuel-efficient diesel powertrain, and a powerful hydraulic hook lift system, the ISUZU 8 Ton Hook Loader Garbage Truck delivers outstanding performance for modern waste collection and container transportation. Its flexibility, durability, and efficient container handling capabilities make it an ideal solution for municipalities, environmental service providers, factories, construction sites, and commercial waste management fleets seeking higher productivity and lower operating costs.

Specification

Category & Item	Specification Description
1. General Chassis Specifications
Overall Dimensions (L×W×H)	7,300 × 2,480 × 2,990 mm
Gross Vehicle Weight (GVW) / Curb Weight	18,000 kg / 7,630 kg
Wheelbase	4,500 mm
Front / Rear Axle Load Capacity	6.3T / 13T
Tire Specification	11.00R20, 6 + 1 tires
Drive Type	4×2
2. Engine Specifications
Engine Type	Diesel
Engine Make / Model	ISUZU / 4HK1-TC50
Maximum Horsepower	205 hp
Emission Standard	Euro 5
3. Transmission Specifications
Transmission Make / Model	ISUZU / MLD6
Gear Configuration	6 Forward + 1 Reverse
Operation Type	Manual
4. Cabin Specifications
Cabin Make / Type	ISUZU
Passenger Capacity	3 Persons
5. Hooklift System Specifications
Lifting and Tipping Capacity	8 t
Maximum System Pressure	25 MPa
Hook Height	1,295 mm
Length of Hook Center to Roller Center	3,255 mm
Maximum Tipping Angle	49°
System Weight	970 kg
Compatible Container Length Range	3.0 – 4.2 m
