BRIEF
This ISUZU Truck Mounted 22 Ton XCMG Crane is a powerful and versatile solution for construction, infrastructure, and heavy lifting tasks, combining the dependable performance of an Isuzu chassis with a comfortable sleeper cab and the impressive reach and maneuverability of an XCMG crane, empowering you to tackle demanding jobs with confidence.
FEATURES
- Unmatched Lifting Power: Boasting a lifting capacity of 22,000 kilograms at a distance of 2.5 meters, this crane allows you to handle even the most challenging loads with ease, while its maximum outreach of 23.42 meters ensures you can reach those seemingly inaccessible areas on your worksite.
- Exceptional Height and Stability: With a maximum lifting height of 25.3 meters achieved when the outriggers are fully extended, this crane truck grants you the ability to tackle high-rise projects or work on uneven terrain. The outriggers themselves extend to a span of 8.4 meters, providing exceptional stability during even the most demanding lifting operations.
- Reliable Performance and Operator Comfort: The robust 8×4 wheel drive configuration of the Isuzu chassis provides excellent traction and maneuverability on challenging terrains, while the powerful Isuzu 6WG1-TCG62 engine delivers 382kW (519 hp) of dependable power. The comfortable sleeper cab features air conditioning and power steering, ensuring operator comfort and reduced fatigue during extended workdays.
- Advanced Crane Technology: The XCMG crane features a five-section boom that retracts to a compact 6.78 meters for easy transport and extends to a maximum length of 24 meters, offering exceptional versatility for various lifting tasks. With a recommended flow rate of 80+50 lpm and an operating pressure of 28 Mpa, the crane delivers smooth and efficient operation.
Additional Information
This impressive machine boasts a Gross Vehicle Weight (GVW) of 44,000 kg, allowing for an ample payload capacity of 22,690 kg, while the crane itself weighs in at 7,600 kg. The engine meets the stringent Euro 6 emission regulations, ensuring environmentally responsible operation.
SPECIFICATIONS:
Category | Description | Value |
---|---|---|
Cab Chassis | Make/Model | ISUZU/QL5440TZZ |
Cab Chassis | Wheel Drive | 8×4 LHD |
Measurement | Overall Size (L × W × H)(mm) | 11800×2550×3980 |
Measurement | Front/Rear Overhang(mm) | 1370/1950mm |
Measurement | Front/Rear Track(mm) | 2140/1855mm |
Measurement | Wheelase(mm) | 2100+4325+1370mm |
Weights | G.C.W(kg) | 64000 |
Weights | Chassis Tare /Curb Weight(kg) | 10960 |
Weights | G.V.W (kg) | 44000 |
Weights | Crane Tare Weight(kg) | 7600 |
Weights | Vehicle Tare /Curb Weight(kg) | 20860 |
Weights | Cargo Box Weight(kg) | 2300 |
Weights | Payload Weight(kg) | 22690 |
Weights | F/R Axle Rating(Ton) | 9+9/13+13 |
Cab | Cab Style | Sleeper Cab |
Cab | Cab Model | VC66 |
Cab | Cab Roof | Standard(low roof) |
Cab | Cab Width | 2400mm |
Cab | Construction | Full steel suspended |
Cab | No. of Seats | 3 |
Cab | Instrument & Controls | standard |
Cab | Driver Seats | air bag |
Cab | Tiltable | Front tiltble |
Cab | Equipment & Device | AC, power steering |
Engine | Make/Model | ISUZU/6WG1-TCG62 |
Engine | Output Power/Speed | 382kW at 1800rpm |
Engine | Max. Torque / Speed | 2250N.m at 900-1300rpm |
Engine | Displacement | 15.681L |
Engine | Engine Type | Water cooled, 6 cylinders ,4 stroke, turbo charged,diesel engine |
Engine | Emission Regulation | EURO 6 |
Transmission | Make/Model | ZF8S |
Transmission | Type | Manual |
Transmission | Gear Numbers | 8 forward +1 reverse |
Transmission | First Gear Ratio | / |
Wheels | Wheel Numbers | 12+1 spare tire |
Wheels | Tires | 315/80R22.5 20PR |
Crane | Technical Data | |
Crane | Rated lifting moment | 56 tm |
Crane | Rated lifting capacity | 22000 kg (2.5m) |
Crane | Max. outreach | 23.42m |
Crane | Max. lines of the hook | 6 |
Crane | Slewing angle | Continuous |
Crane | Boom raising angle | 360° |
Crane | Max. lifting height (the measurement from the ground after the outriggers fully extended) | 25.3m |
Crane | Length of the boom system (retracted) | 6.78m |
Crane | Length of the boom system (fully extended) | 24m |
Crane | Boom sections | 5 |
Crane | Outrigger span (fully extended) | 8.4m |
Crane | Recommended flow rate | 80+50 lpm |
Crane | Operating pressure | 28Mpa |
Crane | Recommended oil tank capacity | 270 L |
Crane | Lifting speed | ≥15 m/min at 4th layer |
Crane | Crane weight | 7600 kg |
