ISUZU 10 CBM Water Tank Truck

ISUZU 10 CBM Water Tank Truck

The ISUZU 10 CBM Water Tank Truck is a heavy-duty 4×2 water transportation and distribution vehicle designed for municipal water supply, road maintenance, construction-site dust suppression, landscaping irrigation, and other applications where large volumes of water need to be transported and distributed efficiently. Built with an 18-ton GVW platform, a 4,600 mm wheelbase, and a large 10 CBM tank, the truck provides a practical balance between carrying capacity, road stability, and operating flexibility, while its single-row cab gives the driver a straightforward and functional working environment for daily commercial operations.

The truck is powered by the 6UZ1-TCG40 engine and matched with an MZW6P manual gearbox featuring 6 forward speeds and 1 reverse gear, providing a dependable powertrain for both urban routes and longer-distance water transportation duties. The 300-liter fuel tank supports extended working cycles, reducing the need for frequent refueling when the vehicle is continuously engaged in municipal or construction operations. Depending on the target market and local regulatory requirements, the vehicle can be configured with Euro 2, Euro 3, or Euro 4 emission standards.

With overall dimensions of 8,450 × 2,500 × 3,350 mm and an 18-ton GVW, this water tanker is particularly suitable for customers who require a larger-capacity vehicle than a light-duty sprinkler truck but still need the maneuverability of a 4×2 configuration. The 10,000-liter carbon steel Q235-B tank provides substantial water-carrying capacity for repeated transportation and distribution cycles, making the vehicle a useful solution for municipal service fleets, contractors, agricultural projects, and infrastructure maintenance operations.

For customers handling different municipal and environmental service requirements, this vehicle can also complement a fleet that includes a sprinkler truck for road watering and dust suppression, while a sweeper truck can be used for routine road-cleaning operations. This makes the 10 CBM water tanker a practical part of a broader municipal maintenance fleet rather than simply a vehicle for transporting water.

Features

10 CBM High-Capacity Water Tank

The centerpiece of the vehicle is its 10 CBM water tank, offering a nominal capacity of 10,000 liters and allowing operators to transport a substantial quantity of water in a single trip. The tank is manufactured from Q235-B carbon steel, a widely used structural material that provides the necessary strength for commercial tanker applications, while the large tank volume helps reduce the number of trips required during road watering, construction, landscaping, and water-supply operations.

Heavy-Duty 4×2 Chassis

The 4×2 configuration provides a sensible combination of load-carrying capability, road performance, and operating simplicity, particularly for customers whose water transportation work is mainly performed on paved roads, urban streets, industrial areas, and established construction routes. With a 4,600 mm wheelbase and an overall length of 8,450 mm, the chassis offers a stable foundation for the large tank body while maintaining practical maneuverability for a vehicle in the 18-ton class.

Reliable 6UZ1-TCG40 Powertrain

The 6UZ1-TCG40 engine is matched with an MZW6P manual transmission offering 6 forward gears and 1 reverse gear, allowing the driver to select an appropriate gear for different road and load conditions. This conventional mechanical powertrain layout is well suited to commercial fleet operation because it is straightforward to operate and designed around the requirements of a heavy-duty water tanker working through repeated transportation cycles.

Flexible Emission Configuration

To accommodate different export markets and regulatory environments, the vehicle can be supplied with Euro 2, Euro 3, or Euro 4 emission configurations according to customer requirements. This flexibility makes the truck suitable for a wider range of international markets where emission regulations, fuel conditions, and fleet standards can differ considerably.

Practical Municipal Applications

The 10 CBM tank capacity makes the vehicle suitable for a broad range of water-related operations, including municipal water transportation, road watering, construction-site dust control, landscaping and agricultural irrigation, industrial water supply, and emergency water delivery. For operations requiring more specialized liquid-waste handling rather than clean-water transportation, customers can also consider a vacuum truck, while the water tanker remains focused on clean-water transportation and distribution duties.

Large Fuel Capacity and Working Range

A 300-liter fuel tank supports longer operating cycles and is particularly useful for fleet operators whose trucks may spend many hours traveling between water sources, construction projects, municipal service areas, or remote work locations. Combined with the heavy-duty chassis and large water tank, this configuration helps the vehicle perform efficiently as a dedicated water transportation unit for demanding daily operations.

Specifications
