ISUZU 5000L Oil Tank Truck
The ISUZU 5000L Oil Tank Truck is a reliable fuel-transportation vehicle designed for safe and efficient delivery of diesel, petroleum products, and other liquid fuels. Built on the durable ISUZU NKR / QL1070A chassis from Qingling ISUZU, this fuel tanker truck combines proven Japanese engineering, excellent mobility, and a professional tank body design to meet the requirements of fuel distribution companies, gas stations, industrial facilities, and commercial transportation operations.
Powered by the ISUZU 4KH1CN6LB diesel engine, the truck delivers 88 kW (120 HP) of power with approximately 290 N·m of torque, providing stable performance for daily fuel transportation tasks. The 3.0L turbocharged engine employs advanced fuel injection technology and meets the Euro VI emission standard, offering improved fuel efficiency, lower emissions, and dependable operation across various operating conditions.
The vehicle adopts a 4×2 drive configuration with a total mass of 7,300 kg and a rated loading capacity of 3,500 kg, making it suitable for medium-duty fuel delivery applications. Its compact dimensions of 5,980 × 2,050 × 2,380 mm and 3,360 mm wheelbase allow flexible operation in urban areas, industrial zones, and narrow transportation routes.
Equipped with a 4,500-liter elliptical fuel tank, the ISUZU oil tanker truck is manufactured using high-quality carbon steel with internal anti-wave plates to improve transportation stability. The tank structure is designed to reduce liquid movement during driving, helping improve vehicle control and operational safety.
The fuel tank system includes a carbon steel fuel pump, Euro-standard aluminum alloy manhole, emergency shut-off valve, oil-gas recovery system, anti-overflow protection base, and professional refueling equipment. These configurations allow the truck to perform fuel loading, unloading, and distribution operations safely and efficiently.
With its strong chassis performance, advanced safety equipment, and practical fuel delivery design, the ISUZU 5000L Oil Tank Truck provides an excellent solution for businesses requiring reliable fuel transportation equipment with long service life and easy maintenance.
Features
Reliable ISUZU Chassis and Efficient Power System
The foundation of the ISUZU 5000L Oil Tank Truck is the dependable ISUZU NKR chassis, which is well known for durability, stability, and excellent operating efficiency. The reinforced chassis structure is designed to support the fuel tank body while maintaining smooth driving performance during transportation.
The vehicle is equipped with an ISUZU 4KH1CN6LB turbocharged diesel engine, featuring a 4-cylinder in-line structure and water-cooling technology. With 88 kW power output and Euro VI emissions compliance, the engine provides a balance between strong performance and economical fuel consumption.
The matching ISUZU MYY6S 6-speed manual transmission ensures smooth gear shifting and efficient power transfer. Combined with hydraulic power steering, ABS, air-over-hydraulic braking, and heavy-duty leaf spring suspension, the truck provides excellent handling and safety during fuel delivery operations.
Key chassis advantages include:
- Strong ISUZU diesel power system
- Efficient Euro VI emission performance
- 6-speed manual transmission
- Heavy-duty suspension design
- Reliable braking system with ABS
- Suitable for urban and regional fuel transportation
Professional 4,500L Fuel Tank Structure
The fuel tank body is one of the most important components of an oil tanker truck. The ISUZU 5000L Oil Tank Truck uses an elliptical-shaped tank manufactured from high-quality carbon steel, providing excellent strength and durability for long-term fuel transportation.
The tank is equipped with internal anti-wave plates that help reduce fuel impact and improve vehicle stability while driving. The single-compartment design provides convenient loading and unloading operations for fuel distribution applications.
The tanker body features:
- 4,500-liter fuel capacity
- High-strength carbon steel construction
- Internal anti-wave protection plates
- Euro-standard aluminum alloy manhole
- Carbon steel fuel pump for loading and unloading
- Oil unloading valve
- Oil-gas recovery system
These configurations ensure safer fuel handling while improving operational efficiency for transportation companies.
Advanced Safety Protection Equipment
Safety is a critical requirement for fuel transportation vehicles. The ISUZU oil tanker truck is equipped with multiple safety systems designed to protect operators, cargo, and surrounding environments.
The installed emergency shut-off valve allows quick fuel flow interruption in emergency situations, while the anti-overflow probe base helps prevent excessive filling during fuel loading operations.
Additional safety equipment includes:
- Sound and light alarm system
- Two fire extinguishers
- Anti-slip walkway on the tank top
- Carbon steel folding guardrail
- Reflective safety markings
- Stainless steel hose storage box
These safety features help the truck comply with professional fuel transportation requirements and improve confidence during daily operations.
Convenient Refueling and Operation Design
The ISUZU 5000L Oil Tank Truck is designed not only for transportation but also for efficient fuel distribution. The vehicle is equipped with a 15-meter self-return refueling reel and fuel nozzle, allowing operators to complete refueling tasks conveniently at different locations.
The integrated fuel dispensing cabinet provides organized storage and improves operation efficiency. Ladder steps and the top anti-slip walkway make tank inspection and maintenance easier while improving operator safety.
The ISUZU NKR single-row cab provides a comfortable working environment for 2-3 passengers. The adjustable suspension driver seat, safety belts, and optional air conditioner help reduce fatigue during long-distance transportation.
With its combination of reliable ISUZU technology, professional tanker equipment, and practical safety features, the ISUZU 5000L Oil Tank Truck is an ideal choice for fuel distributors, industrial users, and commercial transportation companies seeking a durable and efficient liquid fuel delivery solution.
Specification
| Item | Specification |
|---|---|
| Section 1 – Chassis Specifications | |
| Chassis Model | ISUZU NKR / QL1070A |
| Chassis Manufacturer | Qingling ISUZU |
| Total Mass | 7,300 kg |
| Rated Mass | 3,500 kg |
| Curb Mass | 3,650 kg |
| Drive Type | 4×2 |
| Axle Nos. | 2 |
| Axle Load | 2,580 / 4,720 kg |
| Approach / Departure Angle | 24° / 15° |
| Tank Volume | 4,500 L |
| Overall Dimension (L×W×H) | 5,980 × 2,050 × 2,380 mm |
| Driver Cab Capacity | 2-3 persons |
| Front / Rear Suspension | 1,015 / 1,605 mm |
| Wheelbase | 3,360 mm |
| Maximum Speed | 95 km/h |
| Section 2 – Engine & Drivetrain | |
| Engine Model | ISUZU 4KH1CN6LB |
| Engine Manufacturer | ISUZU |
| Engine Type | 4-cylinder in-line, water cooled, turbocharged diesel engine |
| Displacement | 2,999 ml |
| Maximum Power | 88 kW (120 HP) |
| Maximum Torque | Approx. 290 N·m |
| Fuel Type | Diesel |
| Emission Standard | Euro VI |
| Transmission | ISUZU MYY6S 6-speed manual gearbox |
| Gearbox Type | Manual transmission |
| Power Steering | Yes, hydraulic power steering |
| Brake System | Air-over-hydraulic brake system |
| ABS | Equipped |
| Tyre Specification | 7.00R16 |
| Tyre Quantity | 6 + 1 spare |
| Front Tread | Approx. 1,680 mm |
| Rear Tread | Approx. 1,650 mm |
| Suspension | Heavy-duty leaf spring suspension |
| Front Axle Capacity | 2.5 tons |
| Rear Axle Capacity | 4.8 tons |
| Section 3 – Cab Configuration | |
| Cab Type | ISUZU NKR single-row cab |
| Cab Width | Approx. 1,880 mm |
| Passengers | 2-3 persons |
| Air Conditioner | Optional |
| Safety Belt | Installed |
| Driver Seat | Adjustable suspension seat |
| Electrical System | 24V system |
| Section 4 – 4500L Fuel Tank Body Configuration | |
| Tank Shape | Elliptical fuel tank |
| Tank Material | High-quality carbon steel GB standard |
| Tank Capacity | 4,500 liters |
| Compartments | 1 compartment |
| Anti-wave Plates | Installed inside tank |
| Fuel Pump | 1 × Carbon steel fuel pump |
| Pump Function | Fuel loading and unloading |
| Manhole | 1 × Euro standard aluminum alloy manhole |
| Emergency Shut-off Valve | 1 × Sub-sea valve (aluminum alloy) |
| Oil Unloading Valve | Installed |
| Oil-Gas Recovery System | Installed |
| Anti-overflow Probe Base | Installed |
| Top Safety Structure | Carbon steel folding guardrail + anti-slip walkway |
| Fire Extinguishers | 2 units |
| Alarm System | Sound and light alarm system |
| Tool Box | 1 unit |
| Fuel Dispensing Cabinet | Installed |
| Hose Box | Stainless steel hose storage box |
| Fuel Reel | 15m self-return refueling reel |
| Fuel Nozzle | Refueling nozzle installed |
| Ladder Steps | Installed |
| Reflective Marking | Simple reflective logo |
| Painting | Metallic anti-corrosion coating |
