ISUZU 9 CBM Sweeper Truck

ISUZU 9 CBM Sweeper Truck

The ISUZU 9 CBM Sweeper Truck is a heavy-duty municipal road cleaning vehicle designed for efficient sweeping, dust collection, and large-area environmental sanitation operations. With a maximum sweeping width of 3.0 meters, a maximum sweeping capacity of 60,000 m²/h, and a large-capacity cleaning system, this vehicle is well suited for city roads, highways, industrial parks, logistics areas, airports, public squares, and other locations that require reliable and continuous road maintenance.

Designed for demanding sanitation applications, the truck combines a 7,000L garbage tank with a 2,000L water tank, providing sufficient capacity for collecting road debris while supporting water-assisted dust suppression. The maximum inhalation particle size reaches 110mm or more, allowing the sweeping system to collect not only fine dust but also relatively large debris such as leaves, gravel, and other roadside waste.

The vehicle offers a practical combination of cleaning performance and road-going capability, with a maximum driving speed of 90km/h, maximum gradeability of 30%, and a minimum turning diameter of approximately 13.6 meters. Its overall dimensions are 6,950×2,500×3,300mm, while the 3,815mm wheelbase provides a stable platform for the sweeping equipment and large-capacity tanks.

With a curb weight of approximately 6,000kg, a rated capacity of 7,000kg, and a GVW of 11,000kg, the ISUZU 9 CBM Road Sweeper is designed to handle substantial cleaning loads while maintaining dependable driving stability. Its sweeping speed can be adjusted from 3-20km/h, allowing operators to select the appropriate working speed according to road conditions, debris density, and required cleaning quality.

The vehicle also provides practical operating economy, with fuel consumption during road travel of no more than 12L/100km, while sweeping at 8km/h requires approximately 6.5L/h and the reported cleaning consumption is around 2.7L per 10,000m². This makes the truck a practical choice for sanitation contractors and municipal departments looking to balance high productivity with reasonable operating costs.

Features

1. Large-Capacity Cleaning System

The ISUZU 9 CBM Sweeper Truck is equipped with a 7,000L garbage tank, providing ample storage for dust, leaves, sand, gravel, and other road debris collected during daily cleaning operations. The large capacity reduces the frequency of unloading and allows the truck to remain in the working area for longer periods, which is particularly useful for large-scale municipal sanitation projects.

A 2,000L water tank supports the dust suppression system, helping reduce airborne particles during sweeping and improving the overall quality of road cleaning. The combination of garbage collection and water-assisted sweeping allows the vehicle to perform efficiently in both dry and dusty environments.

2. Wide 3-Meter Sweeping Coverage

The vehicle provides a maximum sweeping width of 3.0 meters, allowing it to clean a broad section of road during each pass and significantly reducing the number of passes required to complete a large area. The sweeping speed can be adjusted between 3-20km/h, giving operators greater control over cleaning intensity and working efficiency.

With a maximum sweeping capacity of 60,000m²/h, the truck can efficiently handle urban roads, highways, industrial areas, parking facilities, and other large public spaces where high cleaning productivity is required.

3. Powerful Dust and Debris Suction Capability

The road sweeper truck is designed with a strong suction system capable of handling particles with a maximum inhalation size of 110mm or more. This allows the cleaning equipment to collect a wide variety of road debris rather than being limited to fine dust alone.

By combining mechanical sweeping with powerful suction, the system can effectively remove accumulated dirt, sand, leaves, small stones, and other debris from the road surface, helping maintain a cleaner and safer environment while minimizing the need for manual cleaning.

4. Strong Driving and Gradeability Performance

The vehicle offers a maximum driving speed of 90km/h, allowing it to move efficiently between different cleaning locations without requiring separate transportation equipment. Its 30% maximum gradeability enables the truck to operate on roads with moderate slopes, making it suitable for a wider range of municipal and industrial environments.

The approximately 13.6-meter minimum turning diameter provides practical maneuverability for a vehicle of this size, while the 3,815mm wheelbase contributes to driving stability and balanced weight distribution during both transportation and cleaning operations.

5. Heavy-Duty Load Capacity

With a 6,000kg curb weight, 7,000kg rated capacity, and 11,000kg GVW, the truck provides a substantial load-bearing capability for professional cleaning operations. The robust configuration allows the vehicle to carry significant quantities of collected waste while maintaining stable road performance.

The 1,504mm front track and 1,530mm rear track, together with a minimum ground clearance of 190mm, provide a stable stance and suitable clearance for common urban road conditions. The 24° approach angle and 13° departure angle further improve the vehicle’s ability to negotiate ramps and uneven road sections.

6. Practical Operating Economy

The ISUZU Sweeper Truck is designed to deliver strong cleaning productivity without excessive operating consumption. During normal driving, fuel consumption is specified at no more than 12L/100km, while sweeping operation at approximately 8km/h consumes around 6.5L/h.

The reported cleaning consumption of approximately 2.7L per 10,000m² demonstrates the vehicle’s ability to cover substantial road areas with controlled fuel usage. This balance between cleaning capacity and operating consumption can help municipal sanitation departments improve long-term fleet efficiency.

7. Stable Body Dimensions for Professional Applications

The truck measures 6,950×2,500×3,300mm, providing enough space for its large-capacity cleaning equipment while maintaining a practical overall footprint for professional road operations. The 3,815mm wheelbase contributes to stability, while the carefully balanced front and rear suspension dimensions help support the upper cleaning structure.

The combination of a large garbage tank, water storage capacity, wide sweeping system, and stable chassis makes the ISUZU 9 CBM Road Cleaning Sweeper particularly suitable for continuous-duty applications where high productivity and dependable performance are essential.

Specifications

ITEM	VALUE
Max sweep width	3.0 m
Sweep speed	3-20 km/h
Max sweep capacity	60,000 m³/h
Max inhalation of granularity	2110 mm
Angle of unloading	245°
The volume of water tank	2,000 L
The volume of garbage tank	7,000 L
Max speed	90 km/h
Max gradability	30%
Braking distance	≤10 m
Min turning diameter	≤13.6 m
Fuel consumption (Driving)	≤12 L/100km
Fuel consumption (sweep working at 8km/h)	6.5 L/h
Fuel consumption per 10,000m²	27 L/10,000m²
Curb weight	6,000 kg
Rated capacity	7,000 kg
Gvw	11,000 kg
Overall dimensions (LxWxH)	6,950×2,500×3,300 mm
Wheelbase	3,815 mm
Track front	1,504 mm
Track rear	1,530 mm
Front suspension	1,070 mm
Rear Suspension	1,580 mm
Approach angle	24°
Departure angle	13°
Minimum Ground clearance	190 mm
