SPECIFICATION
General | |||
Brand | ISUZU | ||
Overall dimension | 6350×1980×2750mm | ||
GVW | 6545kg | ||
Tare weight | 4170kg | ||
Emission standard | Euro5 | ||
Front/Rear overhang | 1015/1880mm | ||
Leaf Spring | 8/6+5 | ||
High speed | 95km/h | ||
Chassis | |||
Make | ISUZU | ||
Model | QL1070A6HWY | ||
Fuel type | Diesel | ||
Drive Type | 4×2 | ||
Wheelbase | 3360mm | ||
Front/Rear track | 1504/1425mm | ||
Tyre specs | 7.00R16 | ||
Tyre No. | 6+1 | ||
Front axle loading | 1995kg | ||
Rear axle loading | 4550kg | ||
Engine | |||
Brand | ISUZU | ||
Mode | 4KH1CN5MD | ||
Cylinder | Inline 4-cylinders, | ||
Output power | 85kw | ||
Max horse power | 115hp | ||
Output torque/speed | 177N.m/1500rpm | ||
Gearbox | ISUZU MSB-5SM | ||
Control type | Manually | ||
Displacement | 2.999L | ||
Gear No. | 5 forward+1 reverse | ||
Cab(Crew) | |||
Seat No | 5 | ||
Air conditioner | optional | ||
Color | Red or optional | ||
Superstructure | |||
Material | Aluminum alloy | ||
Structure | Crew cab with 4 doors | ||
Water tanker Capacity | 2000L | ||
Others | 1 manhole+1 pressure relief device+1 indicator of liquid level+1 outlet with valve | ||
Water pump | |||
Brand | Shanghai RONGSHEN | ||
Model | CB10/20 | ||
Rated flow | 20L/[email protected] | ||
Pressure | 1.0MPa | ||
Fire monitor | |||
Brand | Chengdu WST | ||
Model | PS20 | ||
Rated flow | 20L/S | ||
Range | >50m | ||
Working Pressure | <0.7MPa | ||
pitch rotation angle | -30~+70(°) | ||
Horizontal Rotation | 0~360(°) | ||
Weight | ≤25kg | ||
Electric system | |||
Auxiliary lighting | Lighting lamps and the control panel is equipped with lighting, indicator lights, etc. | ||
Strobe lights | Red and blue strobe lights on both sides of the vehicle. | ||
Firefighting light | 35W fire searchlight installed on the rear of the bodywork | ||
Warning device | Long-row red warning lights installed on the top of the cab | ||
The control box for the siren is located in front of the driver. | |||
List of documents carried in the vehicle | |||
No. | Name | Specification | Qty |
1 | Water pipe(snap type) | Φ100x2m | 4 |
2 | Water filter(snap type) | FLF100 | 1 |
3 | Water segregator | FII80/65×2-1.6 | 1 |
4 | Manifold converging | JII1100/65×2-1.0 | 1 |
5 | Fire hose(Insertion type) | 13-65-20 | 6 |
6 | Fire hose(Insertion type) | 3-80-20 | 4 |
7 | Injection Fire hose | 13-65-5 | 1 |
8 | Irregular interface | 65/80 | 1 |
9 | Hose bandage | DT-SB | 4 |
10 | Hose hook | 4 | |
11 | Ground fire hydrant wrench | QT-DS1;400 long | 1 |
12 | Underground hydrant wrench | 860 long | 1 |
13 | Water pipe wrench | FS100 | 2 |
14 | Multifunction water spear | QZG3.5/7.5;65 | 1 |
15 | Multifunction water spear | QHD3.5/7.5;65 | 1 |
16 | Fire extinguisher | 3 kg/ABC | 1 |
17 | Fire ax | QTF-PF; 810mm | 1 |
18 | Fire waist ax | GF-285;390mm | 1 |
19 | Rubber hammer | 1 |
